Fiber Optic Drop Cable Assembly Toneable Flat Drop Cable Patch Cord FTTA Corning Opti-Tap Waterproof Patch Cord
Feature
- Positive mechanical feedback to inform the operator when the connector is fully mated - No cable buckling during or after installation
- Robust bayonet locking for easy, fast and secure mating
- A water-proof, dust-proof and corrosion-resistant design that utilizes metal die cast bulkhead
- Cost savings through the elimination of fiber management in the radio unite is suitable for producing PET plastic containers and bottles in all shapes.
- one single mode fiber
Core Cladding Coating Buffer
| Item | Unit | Specification |
| Attenuation | dB/km | 1310nm≤0.4 1550nm≤0.3 |
| Dispersion | Ps/nm.km | 1285~1330nm≤3.5 1550nm≤18.0 |
| Zero dispersion wavelength | Nm | 1300~1324 |
| Zero dispersion slope | Ps/nm.km | ≤0.095 |
| Fiber cutoff wavelength | Nm | ≤1260 |
| Mode field diameter | Um | 9.2±0.5 |
| Mode field concentricity | Um | <=0.8 |
| Cladding diameter | um | 125±1.0 |
| Cladding non-circularity | % | ≤1.0 |
| Coating/cladding concentricity error | Um | ≤12.5 |
| Coating diameter | um | 245±10 |
| bending, dependence induced attenuation | 1550nm, 1turns,32mm diameter 100rums,60mm diameter | ≤0.5 db |
| Proof test | kpsi | ≥100 |
- Connector Specification
| ITEM | PARAMETER |
| Connector type | PC |
| Insertion Loss | <=0.3db |
| Return Loss | >=50db |
| Fiber mode | Single mode 9/125 |
| Operating wavelength | 1310nm, 1550nm |
| Test wavelength | 1310nm, 1550nm |
| Repeatability | <=0.1 |
| Interchangeability | <=0.2dB |
| Durability | <=0.2dB |
| Fiber Length | 1m, 2m….. any length optional. |
| Length and tolerance | 10cm |
| Operating Temperature | -40C ~ +85C |
| Storage Temperature | -40C ~ +85C |
Product Details
